Specifications

In certain applications the above minimum specification may be adapted to suit clients site and soil conditions.

This specification is to be read in conjunction with the quotation/order and Rent-A-Shade reserve the right to amend the specification depending on availability of materials and the site conditions.

SHADEPORT SPECIFICATIONS

SIZE

SINGLE
DOUBLE
TRIPLE
4 CAR (Not available in Cantilever)

2.8 x 5,0m
5,0m x 5.0m
7,5m x 5,0m
10m x 5,0m

HEIGHT

2,1m CLEARANCE


POSTS

STANDARD
CANTILEVER

ǿ76 x 2.0mm TUBE
ǿ152 X 3,0 mm TUBE

HOOPS

ǿ50 X 2,0mm TUBE


CANTILEVER ARM

ǿ50 X 2,0mm TUBE


SHADECLOTH

DOUBLE STITCHED WITH UV RESISTANT COTTON

TENSION ROPE

10mm POLYSTEEL ROPE AS RECOMMENDED BY SHADECLOTH MANUFACTURERS

PAINT

1 COAT RED OXIDE PRIMER
2 COATS QD WHITE ENAMEL

GUARANTEE

2 YEARS ON WORKMANSHIP & MATERIALS USED
